In the sprinkler extinguishing system calculation using scientific principles, all data presented to date are used and precautions are taken to provide maximum protection. With Grid piping, Loop and Tree installation techniques, we make the best choice and perform the installation to protect your building from fire.
The following criteria are taken into consideration in this choice:
DN25 pipe diameter = 2 sprinklers used
DN32 pipe diameter = 3 sprinklers used
DN40 pipe diameter = 5 sprinklers used
DN50 pipe diameter = 10 sprinklers used
DN65 pipe diameter = 20 sprinklers used
DN80 pipe diameter = 40 sprinklers used
DN100 pipe diameter = 100 sprinklers used
DN125 pipe diameter = 160 sprinklers used
DN150 pipe diameter = 275 sprinklers used
In addition to this standard sprinkler calculation, the possibility of greater protection from fire risk is possible by increasing the number of sprinklers.
When the heat generated by the fire reaches 68 degrees, extinguishing liquid begins to flow through the pipes towards the end of the system at a pressure that will explode the sprinkler tips.
The exploding sprinkler spreads the extinguishing liquids coming from the source to the widest area according to its ability and the fire intervention begins. The main goals during this intervention are to reduce the temperature raised by the fire and suppress the smoke. Achieving these goals will ensure that the fire goes out.
Since the basic principle in sprinkler extinguishing systems is to spread extinguishers over the widest possible area, it is vital to use a sufficient number of sprinklers according to the size of the area to be protected. As the number of sprinklers increases, it becomes easier to penetrate a larger area. Since the ability of extinguishers to reach every possible place and extinguish the fire depends on the number of sprinklers, an error should be made in the sprinkler extinguishing calculation.
The number of sprinklers determined by expert engineers during the project planning phase is also followed during the assembly phase, providing more effective results with a suitable installation. The sprinkler extinguishing systems our company has delivered to date continue their duties with 100% success.
